Heavy Duty Hydraulic Disconnect Compact Design For Horizontal Section Drilling
| Minimum Order Quantity | 1PC |
|---|---|
| Packaging Details | Free Fumigation Wooden Case |
| Delivery Time | 40-60Days |
| Payment Terms | T/T |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product Name | Disconnect Tools | Application | Ultra-long Horizontal Section Drilling, Milling |
|---|---|---|---|
| Installation | Easy Installation | Tool OD (mm) | 45mm-79mm |
| Material | 4140HT | Typical Application | Coiled Tubing/ Cementing/ Well Repairing/ Hydraulic Fracturing/ Milling/ Well Drilling |
| Standard Fulfill | API 5CT | Drilling Fluid Applied | Clean Water Base Mud/ Salty Water Base Mud And Oil Base Mud |
| Temerature Range | No Higher Than 175°C | HS Code | 84122910 |
| HS Code | 84314310 | ||
| Highlight | Heavy Duty Hydraulic Disconnect,Hydraulic Disconnect Compact Design,Horizontal Section Drilling Hydraulic Disconnect |
||
Product Description
Heavy Duty Hydraulic Disconnect
Applications
Designed for ultra-long horizontal section drilling, milling, and well bore flushing operations. Engineered to perform reliably in complex working conditions and harsh environments.
Features
- Compact design - 26% shorter than standard hydraulic disconnects
- Enhanced torque resistance - 40% greater strength compared to conventional models
- Simple activation - releases by dropping ball at well head
Available Sizes
| Model Number | Tool OD (mm) | Tool ID (mm) | Thread Type |
|---|---|---|---|
| 207-450 | 45 | 12 | 1 AMMT B*P |
| 207-508 | 50.8 | 12 | 1-1/2 AMMT B*P |
| 207-540 | 54 | 12 | 1-1/2 AMMT B*P |
| 207-635 | 63.5 | 19 | 1-1/2 AMMT B*P |
| 207-730 | 73 | 23 | 2-3/8 PAC B*P |
| 207-790 | 79 | 27 | 2-3/8 PAC B*P |
