Double Flapper Check Valve With Dual Flapper Sealing Coiled Tubing String Component

  • Double Flapper Check Valve With Dual Flapper Sealing Coiled Tubing String Component
Minimum Order Quantity 1PC
Packaging Details Free Fumigation Wooden Case
Delivery Time 40-60Days
Payment Terms T/T

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Tool OD (mm) 38mm-79mm Tool ID (mm) 14mm-32mm
Thread Type AMMT B*P Or PAC B*P Type Double Flapper Check Valve
Material 4140HT Typical Application Coiled Tubing/ Cementing/ Well Repairing/ Hydraulic Fracturing/ Milling/ Well Drilling
Standard Fulfill API 5CT Drilling Fluid Applied Clean Water Base Mud/ Salty Water Base Mud And Oil Base Mud
Temerature Range No Higher Than 175°C HS Code 84122910
HS Code 84314310
Highlight

Dual Flapper Sealing Check Valve

,

Coiled Tubing Double Flapper Check Valve
Leave a Message
Product Description
Double Flapper Check Valve
Applications
The double flapper check valve is a standard coiled tubing string component. It provides a means to prevent the back flow of well fluids into the coiled tubing.
Features
  • Dual Flapper sealing valve core provides stable sealing performance in both high and low pressure conditions
  • Valve core is made of anti-corrosion material to withstand complex harsh working conditions
  • Compact high pressure pure metal sealing with low pressure non-metallic assist sealing for effective sealing across all pressure ranges
Sizes Availability
Model Number Tool OD (mm) Tool ID (mm) Thread Type
301-380 38 14 1 AMMT B*P
301-430 43 18 1 AMMT B*P
301-450 45 18 1 AMMT B*P
301-508 50.8 18 1-1/2 AMMT B*P
301-540 54 23 1-1/2 AMMT B*P
301-603 60.3 23 1-1/2 AMMT B*P
301-635 63.5 23 1-1/2 AMMT B*P
301-730 73 32 2-3/8 PAC B*P
301-790 79 32 2-3/8 PAC B*P
